Рама

№	Номер	Название
1	1T02001	IMPELLER COVER
2	1T02002	IMPELLER
3	1T02003	TURBINE
4	1T02004	GUIDE WHEEL
5	1T02005	PRESSING PLATE
6	1B01349	POSITION PIN
7	1T02006	O-SEAL RING
8	1T02007	CONE BEARING
9	1T02008	BEARING BASE
10	TC2009	COVER
11	1B02025	WASHER
12	1B01253	WASHER
13	1T02010	OUTPUT SHAFT
14	1T02011	PRESSING PLATE
15	1T02012	BRACKET SEAL RING
16	1B44034	SEAL RING
17	1T02013	COUPLING PLATE
18	1T02014	BEARING
19	1B01146	PIN
20	1B03048	PIN
21	1T02015	BRACKET, SEAL RING
22	1T02016	SEAL RING
23	1T02017	SPACER RING
24	1T02018	PRESSING COVER
25	1T02019	HOUSING
26	1T02020	PLUG
27	1T02021	BRACKET, GUIDE WHEEL
28	1T02023	NUT
29	1T02022	LOCK SHIM
30	1T02023	RETAINER
31	1T02025	COUPLING PLATE, TURBINE
32	1T02025	BEARING
33	1T02026	BEARING CLIP RING
34	1T02027	HOUSING, IMPELLER
35	1T02028	ELASPIC CLAMP
36	1T02029	GEAR RING
37	1T02030	HUB, TURBINE
38	1T02031	PRESSING COVER
39	1T02032	BRACKET, SEAL RING
40	1T02033	SEAL RING
41	1T02034	PLANETARY CARRIER
42	1T02035	ELASPIC RETAINER
43	1T02036	METAL SLEEVE
44	1T02037	SUN GEAR
45	1T02038	CLIP RING
46	1T02039	SPACING
47	1T02040	BEARING LINING
48	1T02041	BEARING
49	1T02034	GASKET, PLANETARY IND
50	1T02042	NEEDLE BEARING
51	1T02044	PLANETARY SHAFT
52	1T02078	PLUG
53	0T02078	FIXED PIN
54	1T02045	PLANETARY GEAR
55	1T02046	CLIP PLATE
56	1T02047	GUIDE PIPE
57	0T03325	SCREEN ASSEM.
58	0T03323	SCREEN GASKET
59	0T03324	SCREEN COVER
60	1T02048	OUTLET PRESSURE VALVE
1	GB783-84	BOLT M8×30
2	GB97.1-85	WASHER 8
3	GB3452.1-82	O-SEAL RING φ15×3
4	GB3783-86	BOLT M12×35
5	GB97.1-85	WASHER 12
6	GB3452.1-82	O-SEAL RING φ17×1.45
7	GB3452.1-82	O-SEAL RING φ150×5.3
8	GB3452.1-82	O-SEAL RING φ47×1.1
9	GB5782-86	BOLT M16×70
10	GB9887-3-88	LIP SEAL Z100,110,11
11	GB5782-86	BOLT M12×70
12	GB3452.1-82	O-SEAL RING φ12×1.8
13	GB3783-86	BOLT M12×30
14	GB3452.1-82	O-SEAL RING φ130×7.0
15	GB894.1-86	RETAINER 56
16	GB894.1-86	RETAINER 85
17	GB693.1-86	RETAINER 85
18	GB3452.1-82	O-SEAL RING φ32.5×3.55
19	GB5783-86	BOLT M10×20
20	GB79-85	SCREW M8×20
21	GB5783-86	BOLT M10×25
22	GB97.1-87	WASHER 10
